Optris – Non-Contact Temperature Measurement for Industry and R&D
Finn & Conway is proud to be partnered with Optris Infrared Sensing to offer their comprehensive product line of Infrared thermometers, thermal imagers and portable thermometers. German engineered and manufactured and at a cost that will stay in your budget!
Optris has been developing and manufacturing innovative infrared measurement devices for non-contact temperature measurement, including stationary IR Thermometers, Infrared Cameras and Handheld Thermometers for point and area measurement, for more than 15 years.
Along with free thermal analysis software, our measurement devices enable constant monitoring and control of virtually every manufacturing process, and reductions in production costs through specific process optimization.
Infrared Thermometers & Pyrometers
Optris infrared thermometers and pyrometers for non-contact spot measurements are ideally suited for precise temperature monitoring across industrial manufacturing, research and development, and functional testing applications. The product portfolio ranges from cost-effective entry-level sensors to rugged, industrial-grade pyrometers utilizing ratio measurement technology for improved accuracy on metal targets in challenging environments where dust, smoke, or contamination can interfere with infrared signals.
Optris offers a comprehensive selection of spectral response options optimized for accurate temperature measurement of metals, plastics, glass, and many other materials. The product line includes sensors designed for extreme temperatures, high-speed measurement and ultra-small target detection. With this broad range of capabilities, the Optris pyrometer portfolio provides reliable solutions for virtually any remote infrared temperature measurement application.
Optris Infrared Cameras
Optris' infrared cameras are fully radiometric stationary thermographic systems with an excellent price-performance ratio. The thermal imaging cameras are connected to a PC via USB and they are immediately ready to be used. Temperature data is displayed through the license-free analysis software Optris PIX Connect. The software also includes two SDKs for Windows and Linux as well as drivers for LabVIEW and MATLAB.
Xi Compact Line
- Motor focus
- Compact industrial imager for temperature measurements from -20 to 900 °C
- Autonomous operation with automatic spot finder and direct analog output - ideal for OEM use (Xi 80)
- Direct Ethernet and RS485 interface (Xi 80)
- Microscope optics for circuit boards and small electronic components down to 240 µm (MFOV) starting at $ 2400
PI Precision Line
- Interchangeable lenses
- Suited for fast processes (up to 1 kHz)
- High thermal sensitivity (up to 40 mK NETD)
- High optical resolution (up to 640 x 480 pixels)
- Laser blocking filters
- Temperature measuring ranges from -20 to 2000 °C
- Different spectral ranges (500 nm / 1 μm / 7.9 μm / 7.5 – 13 μm)
- Cooling accessories for harsh environments up to 315 °C ambient temperature
- Shipped in rugged outdoor case with tripod and individual test report included
- Microscope optics for circuit boards and tiny electronic components down to 85 µm (MFOV) starting at $ 7780
